Windows Web: Prod and Pre-Prod

introduction this document aims to provide comprehensive guidance for performing the fingerprint signing with the help of the mantra mfs110 l1 device in the windows web browser with nsdl as the esigning service provider (esp) in both the production and pre production environment contract signing in production environment prerequisites required below are the prerequisites required to perform the aadhaar based fingerprint signing in the production environment with the help of the mantra mfs110 l1 device 1\ mfs110 driver 2\ mfs110 windows rd service 3\ mantra biometric device l1 (mfs110 l1) below are the steps required to set up the above mentioned drivers to perform the signing steps to follow step 1 visit the mantra official website to install the drivers https //www mantratec com/download/user https //www mantratec com/download/user select the product category “authentication device aadhar” and select the “mfs110 l1” mantra website step 2 click on the driver and download the “mfs110 driver” double click on the downloaded file the installation process will start installation interface step 3 click the “ install ” and the installation process will start once the installation is completed click on the “ finish ” button to complete the installation installation interface step 4 click on the “ rd service ” and download the “ mfs110 windows rd service ” mantra website interface step 5 double click on the downloaded file to start the installation process click on “ next ” click on “ instal l” to install the device installation interface step 6 click on the “ finish ” button to complete the installation of the mfs110 rd service installation interface step 7 insert the biometric device the confirmation will appear at the bottom right side of the screen stating “ device attached ” success message interface step 8 after the above confirmation message a “ framework is ready to use ” message will appear leading to the device ready to perform the signing device ready to use interface step 9 navigate to the signing link sent to the signer’s email (provided while initiating the contract) signing url email step 10 the pre verification page will open, where the user needs to perform verification using a one time otp click on the “ get otp ” button otp verification page step 11 the user will receive the otp on the email provided during contract initiation otp email step 12 enter the otp received via email and click on the “ verify ” button otp verification page step 13 upon successful verification, the user will land on the contract page click on the “ i want to sign ” button to proceed contract page step 14 the nsdl interface will open fill in the aadhaar number the device is automatically detected select the device “ mantra (mfs110) " nsdl interface step 15 tick the consent box double click on the " capture " button to perform the signing nsdl interface step 16 an embedded message will be displayed click the “ ok ” button nsdl interface step 17 a notification will appear on the bottom left side of the screen stating “ put your finger ” nsdl interface step 18 place your finger firmly on the device the finger will be automatically captured and a notification will appear on the bottom left side of the screen stating “capture success” nsdl interface step 19 an embedded confirmation page will appear with a confirmation message stating “ finger captured successfully ” nsdl interface step 20 the user will be automatically redirected to the signed contract where they can see their signature affixed to it click on “ done ” to complete the signing process contract page step 21 the user will see the success page and can click on the “ great ” button or be redirected to the success url set by the contract initiator after 5 seconds success page step 22 the user will receive a confirmation email with the header “ confirmation of signing the document ,” containing the signed contract contract signed email step 23 once all signers have signed the contract, the user will receive another email with the header “your document signing has been finalized successfully,” containing the final signed contract and the audit trail certificate contract signing in pre production environment the mantra mfs110 l1 device is registered for the production environment by default to register the device for the pre production environment please drop an email to the servico\@mantratec com mailto\ servico\@mantratec com along with the device serial number requesting to register the device for the pre production environment prerequisites required below are the prerequisites required to perform the aadhaar based fingerprint signing in the production environment with the help of the mantra mfs110 l1 device 1\ mfs110 driver 2\ mfs110 windows rd service 3\ mantra biometric device l1 (mfs110 l1) below are the steps required to set up the above mentioned drivers to perform the signing in a prep production environment video tutorial to make the setup process for fingerprint signing easier, we have included a video tutorial in the documentation this video offers a step by step guide on how to configure the fingerprint device to perform secure signings https //drive google com/file/d/1kf26chc0efulrr0t9ay8obhov64zepvm/view?usp=sharing https //drive google com/file/d/1kf26chc0efulrr0t9ay8obhov64zepvm/view?usp=sharing steps to follow step 1 visit the mantra official website to install the drivers https //www mantratec com/download/user https //www mantratec com/download/user select the product category “authentication device aadhar” and select the “mfs110 l1” mantra website step 2 click on the driver and download the “ mfs110 driver ” double click on the downloaded file the installation process will start installation interface step 3 click the “i nstall ” and the installation process will start once the installation is completed click on the “ finish ” button to complete the installation installation interface step 4 click on the “ rd service ” and download the “mfs110 windows rd service” mantra website interface step 5 double click on the downloaded file to start the installation process click on “next” click on “install” to install the device installation interface step 6 click on the “ finish ” button to complete the installation of the mfs110 rd service installation interface step 7 insert the biometric device the confirmation will appear at the bottom right side of the screen stating “ device attached ” success message interface step 8 after the above confirmation message a “ framework is ready to use ” message will appear leading to the device ready to perform the signing device ready to use interface step 9 go to the “ local disk (c) " open program files look for the mantra folder and open the rd service folde r click on the mfs110 find config xml file path (c \program files\mantra\rdservice\mfs110) mantra folder files step 10 open the config xml file with notepad permission interface step 11 by default, the rd service is set for production which is shown \<settings env=”p” /> note pad interface step 12 in the \<settings env=”p” / change the “p” to “ pp ” note pad interface step 13 press ctrl+s and save the file on the desktop windows file saving interface step 14 locate the saved config file on the desktop copy the “config” file and paste it into the (c \program files\mantra\rdservice\mfs100) folder a message will pop on the screen click on “ continue ” copying image interface step 15 click the “ replace this file on the destination folder ” the files copied file will replace the old config file replace file interface step 16 to ensure the file is copied successfully open the new saved config file with notepad the \<settings env=”pp” /> will be set note pad interface step 17 search for the “ service ” from the windows settings and click on it windows service setting step 18 the service interface will open look for the “ mantra mfs110 avdm ” click on it besides a taskbar will appear click on the “ restart ” service button serivce interface step 19 the mantra rd service will restart please wait for a second to complete the process serivce interface step 20 plug the mantra mfs110 l1 device into the windows system a confirmation message will appear stating “ device attached ” at the bottom right of the screen service interface step 21 after the confirmation, another message will pop up at the bottom right corner of the screen stating “ you have successfully converted the device into an aadhaar l1 registered device ” service interface step 22 please unplug the device and replug it a confirmation message will appear stating that the device is attached along with a confirmation message “ framework is ready to use ” service interface step 23 open https //rdtest aadhaardevice com/ https //rdtest aadhaardevice com/ and click on “discover avdm” rd test interface step 24 a confirmation message will appear stating “rdservice discover successfully” click the “ ok ” button step 25 navigate to the signing link sent to the signer’s email (provided while initiating the contract) signing url email step 26 the pre verification page will open, where the user needs to perform verification using a one time otp click on the “ get otp ” button otp verification page step 27 the user will receive the otp on the email provided during contract initiation otp email step 28 enter the otp received via email and click on the “ verify ” button otp verification page step 29 upon successful verification, the user will land on the contract page click on the “ i want to sign ” button to proceed contract page step 30 the nsdl interface will open fill in the aadhaar number the device is automatically detected select the device “ mantra (mfs110) " nsdl interface step 31 tick the consent box double click on the " capture " button to perform the signing nsdl interface step 32 an embedded message will be displayed click the “ ok ” button nsdl interface step 33 a notification will appear on the bottom left side of the screen stating “ put your finger ” nsdl interface step 34 place your finger firmly on the device the finger will be automatically captured and a notification will appear on the bottom left side of the screen stating “capture success” nsdl interface step 35 an embedded confirmation page will appear with a confirmation message stating “ finger captured successfully ” nsdl interface step 36 the user will be automatically redirected to the signed contract where they can see their signature affixed to it click on “ done ” to complete the signing process contract page step 37 the user will see the success page and can click on the “ great ” button or be redirected to the success url set by the contract initiator after 5 seconds success page step 38 the user will receive a confirmation email with the header “ confirmation of signing the document ,” containing the signed contract contract signed email step 39 once all signers have signed the contract, the user will receive another email with the header “your document signing has been finalized successfully,” containing the final signed contract and the audit trail certificate
