introduction this document aims to provide comprehensive guidance for performing the fingerprint signing with the help of the mantra mfs110 l1 device in the mobile web browser with emudhra as the esigning service provider (esp) in both the production and pre production environment contract signing in production environment prerequisites required below are the prerequisites required to perform the aadhaar based fingerprint signing in the production environment with the help of the mantra mfs110 l1 device 1\ mfs110 l1 rd service app download from the google play store https //play google com/store/search?q=mfs110+rd+service\&c=apps\&hl=en in 2\ emudhra app download from the google play store https //play google com/store/search?q=emudhra%20app\&c=apps\&hl=en in 3\ mantra biometric device l1 (mfs110 l1) if emudhra apk is required please contact your account or customer success manager to get the apk for the app once you have all the above mentioned prerequisites follow the below steps to set up the mantra mfs110 l1 device to perform the signing steps to follow step 1 before connecting the device to the android mobile please ensure in the mobile settings app the “ otg connection ” toggle is turned on step 2 allow all the permissions that appear on the screen step 3 open the mfs110 l1 rd service application allow all the permissions that are prompted on the screen step 4 as soon as you allow the “all draw over other apps permission” the mobile setting app will open look for the mfs110 rd service app and allow permission to display over the app” step 5 while allowing the permission the device will be automatically detected and a confirmation message will appear ” device is ready to use ” step 6 once all the permissions are allowed open the mfs110 rd l1 service app all the statuses of the app will be displayed in green step 7 navigate to the signing link sent to the signer’s email and mobile number (provided while initiating the contract) step 8 the pre verification page will open, where the user needs to perform verification using a one time otp click on the “ get otp ” button step 9 the user will receive the otp on their email and mobile number provided during contract initiation step 10 enter the otp received via email or mobile number and click the “ verify ” button step 11 upon successful verification, the user will land on the contract page click on the “ i want to sign ” button to proceed step 12 the emudhra interface will open click on “ sign using the mobile app ” step 13 the emudhra app will open the user needs to fill in the aadhar number click on “ select device ” and from the list of devices select the mantra (mfs110) l1 device status will appear as connected a confirmation message will appear click “ ok ‘ emudhra app step 14 tick the consent box and click the “ accept & continue ” step 15 once the above step is completed now you are ready to sign the document click on the “ perform esign ” button step 16 an interface to capture fingerprint will appear place your finger firmly on the device the device will capture the fingerprint step 17 the confirmation of signing will be prompted on the screen click “ ok ” step 18 the user will be automatically redirected to the signed contract where they can see their signature affixed to it click on “ done ” to complete the signing process step 19 the user will see the success page and can click on the “ great ” button or be redirected to the success url set by the contract initiator after 5 seconds step 20 the user will receive a confirmation email with the header “ confirmation of signing the document ,” containing the signed contract along with the text sms step 21 once all signers have signed the contract, the user will receive another email and sms with the header “your document signing has been finalized successfully,” containing the final signed contract and the audit trail certificate contract signing in pre production environment the mantra mfs110 l1 device is registered for the production environment by default to register the device for the pre production environment please drop an email to the servico\@mantratec com mailto\ servico\@mantratec com along with the device serial number requesting to register the device for the pre production environment prerequisites required below are the prerequisites required to perform the aadhaar based fingerprint signing in the pre production environment with the help of the mantra mfs110 l1 device 1\ mfs110 l1 rd service app download from the google play store https //play google com/store/search?q=mfs110+rd+service\&c=apps\&hl=en in 2\ emudhra app please contact your account or customer success manager to get the credentials to access the sandbox app 3\ mantra biometric device l1 (mfs110 l1) once you have all the above mentioned prerequisites follow the below steps to set up the mantra mfs110 l1 device to perform the signing video tutorial to make the setup process for fingerprint signing easier, we have included a video tutorial in the documentation this video offers a step by step guide on how to configure the fingerprint device to perform secure signings https //drive google com/file/d/19wc1i8ishsahlaxa6z 3ty5oboqfp jh/view?usp=sharing https //drive google com/file/d/19wc1i8ishsahlaxa6z 3ty5oboqfp jh/view?usp=sharing steps to follow step 1 open the mfs110 l1 rd service app allow all the permissions to appear on the screen step 2 mfs110 rd service will ask to draw over the app and click the “ allow ” button step 3 the mobile settings app will open from the list of the apps asking to display over the apps look for the mfs110 rd service click on it and turn on the toggle to allow the app to display over the app step 4 click back and open the mfs110 rd service app click on the three dots at the top right of the screen step 5 the settings page of the mfs110 rd service app will open click 7 times on the “settings” written on the taskbar at the top middle of the screen step 6 an interface will appear on the screen to select the environment step 7 click on the drop down and select “ pp ” from the drop down click the “ ok ” button step 8 a confirmation message will appear on the screen stating the “ environment changed from production to pre production ” step 9 before connecting the device to the android mobile please ensure in the mobile settings app the “ otg connection ” toggle is turned on step 10 connect the device allow all the permissions that appear on the screen step 11 after allowing the permission the device inst process will start and a confirmation message will appear stating that the “ device is ready to use ” step 12 navigate to the signing link sent to the signer’s email and mobile number (provided while initiating the contract) step 13 the pre verification page will open, where the user needs to perform verification using a one time otp click on the “ get otp ” button step 14 the user will receive the otp on their email and mobile number provided during contract initiation step 15 enter the otp received via email or mobile number and click the “ verify ” button step 16 upon successful verification, the user will land on the contract page click on the “ i want to sign ” button to proceed step 17 the emudhra interface will open click on “ sign using the mobile app ” step 18 the emudhra app will open the user needs to fill in the aadhar number click on “ select device ” and from the list of devices select the mantra (mfs110) l1 device status will appear as connected a confirmation message will appear click “ ok ‘ emudhra app step 19 tick the consent box and click the “ accept & continue ” step 20 once the above step is completed now you are ready to sign the document click on the “ perform esign ” button step 21 an interface to capture fingerprint will appear place your finger firmly on the device the device will capture the fingerprint step 22 the confirmation of signing will be prompted on the screen click “ ok ” step 23 the user will be automatically redirected to the signed contract where they can see their signature affixed to it click on “ done ” to complete the signing process step 24 the user will see the success page and can click on the “ great ” button or be redirected to the success url set by the contract initiator after 5 seconds step 25 the user will receive a confirmation email with the header “ confirmation of signing the document ,” containing the signed contract along with the text sms step 26 once all signers have signed the contract, the user will receive another email and sms with the header “your document signing has been finalized successfully,” containing the final signed contract and the audit trail certificate
